Axial 1/10 Wraith 1.9 4WD Brushed Rock Crawler with 2.4Ghz Transmitter (Orange) - AXI90074T1
Axial 1/10 Wraith 1.9 4WD Brushed Rock Crawler with 2.4Ghz Transmitter (Orange)
The Axial Wraith 1.9 RTR 1/10 Scale Rock Crawler is a fresh take on a classic platform that delivers what scalers crave - the ability to tackle technical terrain combined with the scale details needed to create an incredibly realistic looking rig.
Refining the proven 2.2 Wraith chassis design, Axial improved ground clearance by reducing the size of its skid plate and lower rails. Boatside sliders on the skid plate improve handling by helping the vehicle slip through and past obstacles. Another huge benefit to the Wraith 1.9 is that the truck comes out of the box with a forward battery tray configuration! This helps optimise weight distribution and lower the CG for improved performance. Finally, the servo has been moved off the axle and into the chassis where it belongs, with a proper CMS/panhard system that gives the truck improved scale looks, without the negative side effects that can be created by home brew systems.
At the front end of the pinched and boat tailed polycarbonate body you'll find a moulded plastic grille, radiator detail, and two large, LED-equipped headlights and a functional opening hood. Raise the hood to discover a replica V8 engine receiver box cover protecting the Spektrum SRX200 receiver from water, dust, and debris.
The Wraith 1.9 truck's drivetrain uses a powerful brushed 540 motor to turn its proven front and rear, single piece AR44 axles. The pinion gear is 6mm above centre, raising the ground clearance and improving driveshaft angles. Axial boosts the overall strength with metal gear construction; large, flex-reducing load bearings; increased gear surface contact; and a gear ratio that's optimised to reduce torque twist.
Adjustable oil-filled, coil over shocks allow you to tune dampening for the best handling on any track. Moulded from durable S30 compound, the officially licensed Nitto Grappler tyres have a large block tread that gets excellent bite on a wide range of surfaces.
Features
- Strong tube chassis with forward-mounted battery position
- Boatside/skid plate for extra clearance
- Chassis-mounted servo for a realistic look
- Easy access to electronics, and adjustable battery tray
- New body design with LED lights, and grille, radiator, fender, and V8 engine details
- Spektrum™ Transmitter and Receiver
- Licensed 1.9 Nitto Trail Grappler M/T tyres on KMC XD229 Machete crawl wheels
- Compact AX10™ transmission
- AR44™ hi-pinion axles for added ground clearance
- WB8 HD Wildboar™ driveshafts
- Dual slipper clutch with 32-pitch gearing
Specifications:
Scale - 1/10
Type – Crawler
Drivetrain - 4WD Shaft Drive
Wheel Size - (53.9mm) Dia, (26mm) Width
Length - 17.8" (451.6mm)
Width - 8.8" (223.3mm)
Height - 8.8" (223.3mm)
Ground Clearance - 2.73" (69.4mm)
Wheelbase - 12.13" (308mm)
Weight - 4.65lb (2.1kg)
In the Box
Axial 1/10 Wraith 1.9 4WD Brushed Rock Crawler (Orange)
Spektrum STX2 Steerwheel Transmitter
Required to Complete
2-3 Cell LiPo or 5-9 Cell NiMh Battery with EC3 Connector
Compatible Battery Charger
4AA Batteries for Transmitter
